GUTMANN systems
GUTMANN systems in the UAE come from Gutmann Middle East LLC, based in Dubai Investments Park. Its published range runs from hinged windows and doors through sliding, lift-and-slide and fold-and-slide doors to curtain walls — stick, semi-unitised and unitised — and a glass railing, so one family of profiles can carry a villa or a low-rise building from the entrance to the facade. We name the exact series in the drawing, fabricate the profiles to the manufacturer's specification in our Dubai factory and fit them with our own crews.
- Gutmann Middle East who supplies it
- Dubai Investments Park where it is based
- windows to facades what the range covers
Why choose aluminium windows?
-
Durable EPDM seals
Three contours of EPDM seals keep the glass off the aluminium and close the gap between sash and frame, so dust, humid salt air and wind-driven rain stay outside.
Learn more -
Foamed thermal inserts
Foamed inserts fill the profile chambers and stop air circulating inside them, so less outside heat and street noise passes through the frame into the cooled room.
Learn more -
Polyamide thermal breaks
Glass-filled polyamide thermal breaks up to 40 mm wide keep the outer and inner shells apart, so the frame holds its shape and its insulation through a UAE summer.
Learn more -
Energy-efficient double glazing
Double glazing up to 60 mm thick puts a sealed gap of still air or gas between the hot street and the cooled room, so less heat crosses the glass into the room.
Learn more
How far the range reaches
-
Dubai
Supplier
Gutmann Middle East LLC, DIP 2
-
GWD series
Windows and doors
Hinged, top-hung and concealed-sash
-
GLS and GFS
Large openings
Lift-and-slide and fold-and-slide doors
-
F and EF series
Curtain walls
Stick, semi-unitised and unitised
-
GL21
Railings
Glass balustrade in the same range
GUTMANN systems by type
The GUTMANN range, grouped by what each series is for. Figures are the manufacturer's published data, and each card links to its source. Which series fits your opening is settled at the free survey.
GUTMANN windows
Casement, tilt-and-turn and fixed windows. The series differ in profile depth, the thickest glass they take and how much heat the frame lets through.
All window types-
Window · projected top-hung
GUTMANN GWD 070SK
Projected top-hung window in the 70 mm series with fibreglass-reinforced polyamide insulating bars; surface-mounted fittings carry heavier sashes than concealed ones.
- Basic depth
- 70 mm
- Glass thickness
- up to 44 mm
- Sash weight
- up to 300 / 180 kg
- Sound insulation
- up to 47 dB (SSK 5)
- Watertightness
- E1200
-
Window · tilt-and-turn · concealed sash
GUTMANN GWD 070i
Window series with concealed sashes and a 70 mm basic depth, offered in a standard and a highly insulated premium version.
- Basic depth
- 70 mm
- Uf
- from 1.7 W/m²K
- Glazing thickness
- up to 46 mm (in the sash)
- Face width
- from 71 mm (tilt-and-turn windows)
- Sound insulation
- up to 47 dB (SSK 5)
GUTMANN doors
Entrance, terrace and balcony doors. What sets the series apart is how heavy a leaf they carry, the threshold and the locking options.
All door types-
Door · single leaf · double leaf
GUTMANN GWD 080
80 mm door series for single and double leaves opening in or out, with side panels, transom lights and an optional panic function.
- Basic depth
- 80 mm
- Infill / glass thickness
- up to 60 mm
- Max. element size (W × H)
- 1500 × 3000 / 3000 × 3000 mm (1 / 2 leaves)
- Burglar resistance
- RC 2 (DIN EN 1627)
- Watertightness
- 1200 Pa
GUTMANN sliding systems
Sliding and lift-and-slide doors for wide openings onto a terrace or pool. The series differ in panel weight, the width of the meeting stile and the threshold height.
Sliding doors-
Sliding · lift-and-slide
GUTMANN GLS 180
Lift-and-slide door with an 80 mm leaf for large glazed openings, built from straight-cut profiles with a symmetrical design inside and out.
- Leaf depth
- 80 mm
- Glass thickness
- up to 60 mm
- Sound insulation
- up to 44 dB
- Burglar resistance
- up to RC 2 / WK 2
- Watertightness
- E1350
GUTMANN facade systems
Curtain walling and structural glazing for villas, offices and retail. On a facade the series is chosen by span, wind load and how the glass is held.
Curtain wall glazing-
Facade · curtain wall · structural glazing
GUTMANN F50/F60
Stick curtain wall with a 50 or 60 mm face width; mullion and transom share one straight-cut profile, with structural-glazing, semi-SG and visual-SG versions.
- Face width
- 50 or 60 mm
- Us
- 0.9–1.5 W/m²K (DIN EN ISO 10077-2)
- Watertightness
- 1500 Pa
Values are the manufacturer's published figures for the series; the actual value depends on the configuration — glass, size and hardware.
Profile Systems
-
Schuco
Learn more about SchucoSchüco aluminium systems carry large panes on slim frames — for villas, apartments and offices where the view matters.
-
GUTMANN
Learn more about GUTMANNGUTMANN systems are offered by Gutmann Middle East LLC, based in Dubai Investments Park: hinged windows and doors, sliding and lift-and-slide doors, curtain walls and glass railings
-
Deceuninck
Learn more about DeceuninckDeceuninck uPVC profiles are designed in Belgium for superior insulation, weather resistance and a sleek finish. A popular choice for energy-efficient homes across Europe
-
Cortizo
Learn more about CortizoCortizo aluminium systems combine precise Spanish engineering with high thermal and acoustic performance. A reliable choice for windows, doors and facades that need to perform in demanding climates
-
Montana 120
Learn more about Montana 120Montana 120 is a thermal-break sliding series from Gulfex (Gulf Extrusion LLC), with the profile extruded here in Dubai. A straightforward choice for sliding windows and balcony doors of ordinary size
-
TB-600
Learn more about TB-600TB-600 is the thermal-break hinged window and door series of Gulfex (Gulf Extrusion LLC). The profile is extruded in Dubai, and the same maker covers sliding, folding and curtain-wall systems
-
ALUK
Learn more about ALUKALUK is an Italian aluminium systems brand known for slim, minimalist frames that maximise glass area without compromising strength. Perfect for architectural projects that call for a light, contemporary look
-
Vetromax
Learn more about VetromaxVetromax combines advanced glazing technology with aluminium framing for maximum light, strength and energy efficiency. A modern solution for panoramic windows and glass facades
-
REHAU
Learn more about REHAUREHAU uPVC systems are engineered in Germany for outstanding thermal insulation, soundproofing and long-term durability. A proven choice for energy-efficient windows and doors worldwide
Why should you buy aluminium windows?
- They have high strength and durability.
- Aluminium windows are resistant to corrosion.
- Aluminium windows are resistant to deformation.
- The lightweight nature of aluminium windows makes installation easier.
- A modern and stylish appearance.
- These windows require minimal maintenance.
Articles
Profile Options
Consult with a specialist
Profile finish and coating options
Powder coating in any shade of the RAL palette; the colour is confirmed against a physical sample at the survey.
Anodising builds an oxide layer on the profile itself, so the colour belongs to the metal rather than to a film on top of it and cannot peel.
Wood-grain and stone-effect finishes are transferred onto the powder coating. The profile keeps the strength of aluminium and never needs repainting.
Available colours (200+ RAL shades)
- White
- Anthracite
- Brown
- Black
- Grey-anthracite
- Grey
Anodised finishes
- Natural silver
- Champagne
- Light bronze
- Medium bronze
- Dark bronze
- Black anodised
Wood-grain and special effects
- Golden oak
- Walnut
- Dark oak
- Concrete
- Basalt
- Wenge
Let's calculate
the cost of glazing
Get a free calculation for your windows — just leave your number, we'll reply on WhatsApp within 15 minutes.
What we take off a GUTMANN job
- Survey of the opening and the wall around it Engineer on site within 48 hours
- Series matched to the opening Window, door, sliding or facade module
- Glass set against the building code Dubai Building Code limits for the elevation
- Finish agreed against a sample in daylight Judged on the wall, not on a colour chart
- Fabrication to GUTMANN's specification Cut, machined and assembled in Dubai
- Fitting, sealing and a water test Carried out by our own crews
Popular ready-made solutions
- Villa glazing
- Classic windows
- French windows
- Tilt-and-turn windows
- Top-hung windows
- Patio door
- Classic door
- Panoramic sliding doors
- Panoramic folding accordion doors
Garden room at a villa
Thermal-break frames and solar-control glass
Two-storey villa glazing
Sliding doors to the terrace, windows above
Panoramic villa glazing
Slim frames, glass from floor to ceiling
Visit our window design showroom
See profiles, glass units and hardware in person and meet the engineers who draw your project. Come with the plans or photos of the openings.
The Pinnacle Building · Sheikh Zayed Road
- Address
- The Pinnacle Building, Sheikh Zayed Road, Office 607, Dubai
- Hours
- Mon–Fri: 9:00 – 18:00
Our main products
Our company manufactures aluminium structures with subsequent installation at the glazing site.
Pricing
Aluminium Windows and Doors Calculator
Choose the options — we’ll send the price on WhatsApp
What are we making
Shape and opening
Size
Width and height: 300–6000 mm. Not sure? Clear the fields — we’ll measure at the free survey.
Width under 300 mm — check that it is in millimetres.
Width over 6000 mm — we’ll confirm it at the survey.
Height under 300 mm — check that it is in millimetres.
Height over 6000 mm — we’ll confirm it at the survey.
Enter a whole number of units, 1 or more.
Glazing unit
Extras
Do you need a windowsill?
Do you need a coloured profile?
Do you need installation?
Frequently asked questions
Gutmann Middle East LLC, based in Dubai Investments Park 2. Its website, gutmann.ae, lists the systems it offers: GWD windows and doors, SC89, SC115 and Vision One sliders, GLS lift-and-slide and GFS fold-and-slide doors, F- and EF-series curtain walls and the GL21 glass railing. The figures on this page are taken from those system pages, and the drawing names the exact series we fit.
It depends on the width and on how the opening should move. For large, heavy panels onto a pool or a garden the lift-and-slide doors (GLS 125, GLS 180) are the usual type; where the whole wall should open, the GFS fold-and-slide stacks the leaves to one side; for a thin frame line there is the Horizon minimal slider. We settle the choice at the survey against the size, the wind exposure and the glass each panel has to carry.
Yes. Next to the windows and doors the range has stick curtain walls (F35 slim, F50/F60 and a staggered version), a semi-unitised system (F80 CS) and unitised ones (EF 68/EF 68+ and a unitised curtain wall). On a villa or a low-rise building that lets the entrance, the windows and the glazed wall share one family; on a tower the facade system is chosen by the engineer's wind-load and movement calculation first.
No, and we are careful with that word. No systems house has licensed us, and we never let a quote imply otherwise. The profiles, gaskets and hardware come through the supplier, and everything after that — cutting, machining, assembly, glazing, fitting — is done by us in Dubai to the manufacturer's specification. We also build our own aluminium windows here, which is a separate line at a separate price, and every quote states plainly which of the two it is pricing.
