Gulfex Montana sliding systems
A sliding series extruded in Dubai by Gulfex (Gulf Extrusion LLC), the aluminium plant of the Al Ghurair group, and drawn around UAE conditions rather than adapted to them afterwards. The starting assumptions are the local ones: sun load on the glass, sand in the track, salt in the air along the coast and wind pressure on a balcony forty floors up. Because the profile is pressed in the same city, it reaches our workshop without a shipping leg. We fabricate it to the manufacturer's specification and fit it with our own crews.
- Gulfex extruded by
- Dubai where it is pressed
- sliding opening type
Why choose aluminium windows?
-
Durable EPDM seals
Three contours of EPDM seals keep the glass off the aluminium and close the gap between sash and frame, so dust, humid salt air and wind-driven rain stay outside.
Learn more -
Foamed thermal inserts
Foamed inserts fill the profile chambers and stop air circulating inside them, so less outside heat and street noise passes through the frame into the cooled room.
Learn more -
Polyamide thermal breaks
Glass-filled polyamide thermal breaks up to 40 mm wide keep the outer and inner shells apart, so the frame holds its shape and its insulation through a UAE summer.
Learn more -
Energy-efficient double glazing
Double glazing up to 60 mm thick puts a sealed gap of still air or gas between the hot street and the cooled room, so less heat crosses the glass into the room.
Learn more
What a UAE-drawn slider does differently
-
Drained channel
Sill
Sand and water leave the track
-
Roller carriages
Running gear
Rated to the weight of the panel
-
Interlocking stiles
Meeting rails
Sealed where two panels cross
-
Brush and EPDM
Sealing
Two barriers against fine dust
-
Pressed in Dubai
Profile
No shipping leg before fabrication
Gulfex Montana systems by type
The Gulfex Montana range, grouped by what each series is for. Figures are the manufacturer's published data, and each card links to its source. Which series fits your opening is settled at the free survey.
Gulfex Montana sliding systems
Sliding and lift-and-slide doors for wide openings onto a terrace or pool. The series differ in panel weight, the width of the meeting stile and the threshold height.
Sliding doors-
Sliding · fixed top/bottom lights
Gulfex Montana 120
Thermally broken 120 mm aluminium sliding system built from one frame and one sash profile used on all four sides; two to four sashes, with top and bottom fixed lights.
- System depth
- 120 mm
- Thermal break
- 16 mm
- Glass thickness
- 24 mm
- Performance class
- H-HC40
- Ust (2017 catalogue)
- 3.3 W/(m²K)
-
Sliding · multi-track sliding (3 tracks) · multi-track sliding (4 tracks)
Gulfex Montana 120 Multi-Track
Multi-track version of the Montana 120 thermal-break sliding system, with three or four tracks for wider openings.
- Number of tracks
- 3 – 4
- Glass thickness
- 24 mm
Values are the manufacturer's published figures for the series; the actual value depends on the configuration — glass, size and hardware.
Profile Systems
-
Schuco
Learn more about SchucoSchüco aluminium systems carry large panes on slim frames — for villas, apartments and offices where the view matters.
-
GUTMANN
Learn more about GUTMANNGUTMANN systems are offered by Gutmann Middle East LLC, based in Dubai Investments Park: hinged windows and doors, sliding and lift-and-slide doors, curtain walls and glass railings
-
Deceuninck
Learn more about DeceuninckDeceuninck uPVC profiles are designed in Belgium for superior insulation, weather resistance and a sleek finish. A popular choice for energy-efficient homes across Europe
-
Cortizo
Learn more about CortizoCortizo aluminium systems combine precise Spanish engineering with high thermal and acoustic performance. A reliable choice for windows, doors and facades that need to perform in demanding climates
-
Montana 120
Learn more about Montana 120Montana 120 is a thermal-break sliding series from Gulfex (Gulf Extrusion LLC), with the profile extruded here in Dubai. A straightforward choice for sliding windows and balcony doors of ordinary size
-
TB-600
Learn more about TB-600TB-600 is the thermal-break hinged window and door series of Gulfex (Gulf Extrusion LLC). The profile is extruded in Dubai, and the same maker covers sliding, folding and curtain-wall systems
-
ALUK
Learn more about ALUKALUK is an Italian aluminium systems brand known for slim, minimalist frames that maximise glass area without compromising strength. Perfect for architectural projects that call for a light, contemporary look
-
Vetromax
Learn more about VetromaxVetromax combines advanced glazing technology with aluminium framing for maximum light, strength and energy efficiency. A modern solution for panoramic windows and glass facades
-
REHAU
Learn more about REHAUREHAU uPVC systems are engineered in Germany for outstanding thermal insulation, soundproofing and long-term durability. A proven choice for energy-efficient windows and doors worldwide
Let's calculate
the cost of glazing
Get a free calculation for your windows — just leave your number, we'll reply on WhatsApp within 15 minutes.
Profile Options
Consult with a specialist
Profile finish and coating options
Powder coating in any shade of the RAL palette; the colour is confirmed against a physical sample at the survey.
Anodising builds an oxide layer on the profile itself, so the colour belongs to the metal rather than to a film on top of it and cannot peel.
Wood-grain and stone-effect finishes are transferred onto the powder coating. The profile keeps the strength of aluminium and never needs repainting.
Available colours (200+ RAL shades)
- White
- Anthracite
- Brown
- Black
- Grey-anthracite
- Grey
Anodised finishes
- Natural silver
- Champagne
- Light bronze
- Medium bronze
- Dark bronze
- Black anodised
Wood-grain and special effects
- Golden oak
- Walnut
- Dark oak
- Concrete
- Basalt
- Wenge
Articles
Why should you buy aluminium windows?
- They have high strength and durability.
- Aluminium windows are resistant to corrosion.
- Aluminium windows are resistant to deformation.
- The lightweight nature of aluminium windows makes installation easier.
- A modern and stylish appearance.
- These windows require minimal maintenance.
Our main products
Our company manufactures aluminium structures with subsequent installation at the glazing site.
Visit our window design showroom
See profiles, glass units and hardware in person and meet the engineers who draw your project. Come with the plans or photos of the openings.
The Pinnacle Building · Sheikh Zayed Road
- Address
- The Pinnacle Building, Sheikh Zayed Road, Office 607, Dubai
- Hours
- Mon–Fri: 9:00 – 18:00
Popular ready-made solutions
- Villa glazing
- Classic windows
- French windows
- Tilt-and-turn windows
- Top-hung windows
- Patio door
- Classic door
- Panoramic sliding doors
- Panoramic folding accordion doors
Garden room at a villa
Thermal-break frames and solar-control glass
Two-storey villa glazing
Sliding doors to the terrace, windows above
Panoramic villa glazing
Slim frames, glass from floor to ceiling
How we build a Montana sliding unit
- Opening measured and checked for square Engineer on site within 48 hours
- Leaf count decided by the span Two, three or four panels on the track
- Running gear sized to the glass weight Carriages chosen, never assumed
- Glass to the Dubai Building Code on every facade Anything above the minimum is chosen by orientation
- Fabrication in our Dubai factory Profile arrives from across the same city
- Installation, levelling and adjustment Track set so a panel moves with one hand
Pricing
Aluminium Windows and Doors Calculator
Choose the options — we’ll send the price on WhatsApp
What are we making
Shape and opening
Size
Width and height: 300–6000 mm. Not sure? Clear the fields — we’ll measure at the free survey.
Width under 300 mm — check that it is in millimetres.
Width over 6000 mm — we’ll confirm it at the survey.
Height under 300 mm — check that it is in millimetres.
Height over 6000 mm — we’ll confirm it at the survey.
Enter a whole number of units, 1 or more.
Glazing unit
Extras
Do you need a windowsill?
Do you need a coloured profile?
Do you need installation?
Frequently asked questions
The assumptions the designer started from. A system drawn for a temperate market optimises around winter heat loss; one drawn here starts from the summer instead — a sash that sits in the sun all afternoon and has to stay straight, a track that fills with sand every shamal, coastal salt working on the finish, and wind pressure on the balcony side of a tower. That shows up in the sill drainage, the sealing arrangement and the finish options rather than in one headline figure.
A slider keeps its panels in the plane of the opening and lets the track carry the glass, which suits wide spans and high floors where a stacked leaf would catch the wind. A bi-fold clears the whole opening but parks the leaves to one side and puts more moving hardware out in the weather. On most UAE terraces the slider is the tighter, quieter answer; where the point is to make the wall disappear entirely, the bi-fold wins.
Grit in the channel is what wears rollers and turns a light panel heavy, so the sill is the part that matters. A drained channel lets sand and rainwater out instead of packing them against the carriage. After that it is upkeep rather than specification: rinsing the track out after a sandstorm and keeping the drainage slots clear does more for the life of the running gear than anything written on a data sheet.
It is a supply question, not a quality one. Aluminium is extruded to an alloy and temper wherever the press happens to stand, and a plant working for the regional market is held to that discipline like any other. What being local changes is the distance between the press and the workshop: less to go wrong in transit, no container schedule between a corrected drawing and a remade frame, and a straightforward order running three to five weeks from the approved drawing.
